Cisco ASR1002 Dubai

Cisco ASR1002 Dubai delivers the route processor for control plane embedded the services processor for data plane traffic as well as the carrier card which is designed to house I/O modules, share port adopters all integrated in the chassis.

Description

Cisco ASR1002 Router Dubai

Cisco ASR1002 Dubai delivers the route processor for control plane embedded the services processor for data plane traffic as well as the carrier card which is designed to house I/O modules, share port adopters all integrated in the chassis. Cisco ASR1002 Dubai comes with 4 build-in SFP ports and 3 box slots for I/O connectivity. The integrated the route processor comes by default with 4Gb DRAM, upgradeable to 8, 16GB.

Features

Redundant hardware components and power supplies-

  • Provides system and business continuity.
  • Redundant Route Processors and Embedded Services Processors in ASR 1006 and ASR 1013.
  • Redundant instances of Cisco IOS XE Software in ASR 1001, ASR 1001-X,Cisco ASR1002 Dubai, ASR 1002-X, and ASR1004.

Stateful inter-chassis redundancy-

  • Redundant hardware combined with modular software contains faults preventing systemwide failure.
  • Enables redundancy across routers by using a pair of routers to act as backup for each other. Provides 99.999% (“five-nines”) availability for consistent, high-performance user application experiences.

Cisco QuantumFlow Processor-based platform-

Enables advanced services to operate at high speeds without the need for additional hardware or blades.

Hardware acceleration-

Features like QoS, crypto, and access control lists (ACLs) are processed in hardware.

Technical Details

Product Code Cisco ASR 1002
Rack Height 2RU
System Bandwidth 2.5G (default) / 5G, 10G, 20G (upgrade)
Router Processor (RP) Quad-core 2.13Ghz processor
Build-in Gigabit Ethernet port 4 x SFP ports
Redundancy Software (license purchase separately)
Cisco ASR 1000 Series ESP 1 ESP slot
SIP and Ethernet line card Integrated ASR 1000-SIP10, not upgradable
Rack-mounting 19-inch
DRAM Memory 4GB-shared across RP and SIP
Flash Memory 8 GB
Shared port adapters 3 SPA slots
External USB flash memory 1-GB USB flash-memory support
