Description

PowerEdge MX750c Blade Server Dubai

Unleashing Scalability with the Dell EMC PowerEdge MX750c Dubai Compute Sled

The Dell EMC PowerEdge MX750c Dubai redefines modular computing by integrating seamlessly into the PowerEdge MX kinetic infrastructure ecosystem. Designed for high-performance workloads, this server sled offers unmatched flexibility and scalability, making it the perfect fit for IT environments that demand excellence in virtualization, containerization, software-defined storage (SDS), software-defined networking (SDN), and database analytics.

High-Performance Modular Innovation

Powered by up to two 40-core 3rd Generation Intel® Xeon® Scalable processors, the PowerEdge MX750c Dubai delivers a revolutionary computing experience. Its single-width, fully configurable design enables advanced workloads while supporting next-generation IT requirements.

Key Features at a Glance

Memory Versatility: Equipped with up to 32 DDR4 DIMM slots, enabling configurations of up to 4 TB.
Persistent Memory: Supports up to 16 slots for Intel® Optane™ DC persistent memory (DCPMM).
Flexible Storage Options: Allows for up to six 2.5-inch SAS/SATA HDD/SSD or NVMe PCIe SSD drives.
Enhanced Boot Capabilities: Features options like the M.2 Boot Optimized Storage Solution (BOSS) or Internal Dual microSD Module (IDSDM).
High-Speed Storage: Offers support for Express Flash NVMe PCIe SSD for direct-attached storage needs.

This sled integrates effortlessly into the PowerEdge MX7000 chassis, with the capacity to host up to eight MX750c servers, ensuring maximum compute density and value for forward-thinking IT environments.

Engineered for Cutting-Edge IT Workloads

The PowerEdge MX750c Dubai is tailored for organizations seeking superior performance across:

Virtualized and containerized environments.
Software-defined storage and networking.
Data-centric applications such as advanced analytics.
Composable Disaggregated Infrastructure (CDI) for modern IT strategies.

Seamless Management with Dell EMC OpenManage

Simplify operations and enhance productivity with the Dell EMC OpenManage systems management portfolio. OpenManage Enterprise – Modular enables multi-chassis management exclusive to the MX ecosystem, ensuring effortless integration and improved efficiency.

Highlighted Capabilities

Visibility and Control: Built-in telemetry streaming, thermal management, and RESTful API with Redfish simplify server management.
Intelligent Automation: Enhances collaboration between system capabilities and human actions for seamless productivity.
Streamlined Updates: Integrated change management tools deliver zero-touch configuration and efficient update planning.
Full-Stack Integration: Compatibility with platforms like Microsoft, VMware, ServiceNow, and Ansible provides unparalleled operational flexibility.

Security at Every Stage

Built with a cyber-resilient architecture, the PowerEdge MX750c Dubai ensures robust security throughout its lifecycle, from deployment to retirement.

Proactive Security Features

Trusted Boot: Cryptographically anchored silicon root of trust for a secure start.
Firmware Integrity: Protects firmware with digitally signed packages.
Configuration Lockdown: Prevents unauthorized changes to firmware or settings.
Data Wipe: Securely removes data from storage devices and memory using System Erase.

Exceptional Value for Modern Businesses

For organizations striving to achieve high compute density, enhanced performance, and operational flexibility, the Dell EMC PowerEdge MX750c Dubai is the ideal solution. It excels in:

General-purpose IT tasks and virtualization.
Containerization and software-defined infrastructures.
Data-intensive workloads like advanced database analytics.

By combining modular design, high-powered computing, and integrated security, the PowerEdge MX750c Dubai addresses the evolving demands of IT infrastructure, paving the way for scalable innovation and growth.

Features and Design

Your innovation engine

The Dell EMC PowerEdge MX750c Dubai, powered by up to two 3rd Generation Intel^® Xeon^® Scalable processors, is a full-featured, high-performance modular server for exceptional scalability.

Modular compute sled ideal for emerging workloads

The Dell EMC PowerEdge MX750c Dubai is designed for the PowerEdge MX7000 kinetic infrastructure ecosystem, and is the latest addition to the PowerEdge MX modular infrastructure portfolio. Up to eight of these dual socket compute sleds can fit within an existing PowerEdge MX7000 module chassis.

Maximizes density and performance in each sled by supporting up to two 3rd Generation Intel^® Xeon^® Scalable processors offering up to 40-cores each.
Supports eight memory channels per CPU with up to 32 DDR4 DIMMs at 3200 MT/s in each sled.
Address substantial throughput improvements with PCIe Gen 4 and up to 6 NVMe drives per sled.

Technical Specifications

Processor

- Up to two 3rd Generation Intel® Xeon® Scalable processors with up to 40 cores per processor.

Operating System

- Canonical® Ubuntu® Server LTS.
- Citrix® Hypervisor®.
- Microsoft® Windows Server® with Hyper-V.
- Red Hat® Enterprise Linux.
- SUSE® Linux Enterprise Server.
- VMware® ESXi®/vSAN.

Chipset

- Intel® C620 series chipset with optional Intel® QuickAssist Technology.

Memory

- DIMM Speed: Up to 3200 MT/s.
- Memory Type: RDIMM, LRDIMM, Intel® Persistent Memory 200 series (BPS).
- Memory Module Slots: 32 DDR4 DIMM slots.
- Maximum RAM:
  - RDIMM: Up to 2 TB.
  - LRDIMM: Up to 4 TB.
  - Intel® Persistent Memory 200 series (BPS): Up to 8 TB.

Storage

- Front Bays:
  - Up to 4 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) with max 7.6 TB per drive.
  - Up to 6 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) with max 7.6 TB per drive.
- Storage Controllers:
  - Internal Controllers: PERC H755 MX, PERC H745P MX, HBA350i MX.
  - External Controllers: PERC H745P MX, HBA330 MMZ.
  - Software RAID: S150.
- Internal Boot:
  - Boot Optimized Storage Subsystem (BOSS-S1): HWRAID with 2 x M.2 SSDs (240 GB or 480 GB).
  - Internal Dual SD Module or USB.

Security

- TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ.
- Digitally Signed Firmware.
- Chassis Intrusion Alert.
- Secure Boot.
- Secure Erase.
- Silicon Root of Trust.
- System Lockdown (requires iDRAC Enterprise or Datacenter).

Management

- Embedded / At-the-Server:
  - iDRAC9, iDRAC Direct, iDRAC Service Module.
- Consoles:
  - OpenManage Enterprise.
  - OpenManage Power Manager plugin.
  - OpenManage SupportAssist plugin.
  - OpenManage Update Manager plugin.
  - OpenManage Enterprise Modular Edition.
- Mobility:
  - OpenManage Mobile.
- Tools:
  - RACADM CLI, iDRAC RESTful API with Redfish, IPMI, System Update Utility, Update Catalogs.
- OpenManage Integrations:
  - BMC® Truesight, Microsoft® System Center, RedHat® Ansible Modules, VMware® vCenter and vRealize Operations Manager.
- OpenManage Connections:
  - IBM Tivoli® Netcool/OMNIbus, IBM Tivoli® Network Manager IP Edition, Micro Focus® Operations Manager, Nagios® Core, Nagios® XI.

Ports

- Front Ports:
  - 1 x iDRAC Direct port (Micro-AB USB).
  - 1 x USB 3.0.
- Internal Ports:
  - 1 x USB 3.0.

Networking Options

- MX7000 chassis Fabric options:
  - Up to 2 pairs of redundant general-purpose switch or pass-through modular bays (Fabrics A and B).
  - Redundant pair of storage-specific switch bays (Fabric C).
- Supports up to 25 Gb CNA/NIC per port for Mezz A/B, 32 Gb Fibre Channel, 12 Gbps SAS for Mezz C.

Slots

- One x16 PCIe Gen4 slot for Mezz A – connected to processor 1.
- One x16 PCIe Gen4 slot for Mezz B – connected to processor 2.
- One x16 PCIe Gen4 slot for mini-Mezz card – connected to processor 2.
- One x16 PCIe Gen4 slot for PERC – connected to processor 1.
- Two x8 PCIe Gen4 connectors for NVMe drive – connected to processor 1.
- One x8 PCIe Gen4 connector for NVMe drive – connected to processor 2.
- Two x4 PCIe Gen3 slots for BOSS M.2 HW RAID card – connected to Platform Controller Hub (PCH).
