APC Smart-UPS SRT 8000VA Dubai

APC Smart-UPS SRT 8000VA Dubai provides customers with a reliable source of Uninterruptible power even in demanding power environments, including very wide input voltage window, extremely tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.

Category:

Description

APC Smart-UPS SRT 8000VA Dubai

The APC Smart-UPS SRT 8000VA Dubai is integrated with Smart-UPS On-Line which provides high density, true double-conversion on-line power protection for servers, voice / data networks, medical labs, and light industrial applications. Capable of supporting loads from 1 to 20kVA in a rack/tower convertible form, the Smart-UPS On-Line is available from 2U to 12U.
APC Smart-UPS SRT 8000VA Dubai provides customers with a reliable source of Uninterruptible power even in demanding power environments, including very wide input voltage window, extremely tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.

Key Features

  • Max Configurable Power (Watts) – 8.0 KWatts / 8.0 kVA
  • Output Connections – 6x IEC 320 C13 (Battery Backup), 4x IEC 320 C19 (Battery Backup), 1x Hard Wire 3-wire (H N + G) (Battery Backup), 3x IEC Jumpers (Battery Backup)
  • Input Connections – Hard Wire 3 wire (1PH+N+G), Hard Wire 5-wire (3PH + N + G)
  • Interface Port(s) – RJ-45 10/100 Base-T, RJ-45 Serial, Smart-Slot, USB
  • Green mode
    • APC Smart-UPS SRT 8000VA Dubai has a patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection
  • Battery failure notification
    • APC Smart-UPS SRT 8000VA Dubai comes with convenient battery notifications which provide early-warning fault analysis on batteries enabling timely preventive maintenance
  • LCD graphics display
    • Text and mimic diagrams that display modes of operation, system parameters and alarms
  • 10/100 BaseT Connection
    • Connect the APC Smart-UPS SRT 8000VA Dubai to a network using a 10 or 100 BaseT connection
  • Safety-agency approved
    • Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
  • ECO Mode
    • APC Smart-UPS SRT 8000VA Dubai has an integrated operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection.
  • User-replaceable batteries
    • Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR).
  • Rack/Tower convertible
    • Protects the initial investment in the APC Smart-UPS SRT 8000VA Dubai when migrating from tower to rack-mount environment.

APC Smart-UPS SRT 8000VA – Technical Specifications

Device Type UPS – rack-mountable
Height (Rack Units) 6U
Color Black
Power Device
UPS Technology On-line
Input Voltage AC 230 V
Frequency Provided 50/60 Hz
Frequency Required 45 – 65 Hz
Input Connectors Hardwire 5-wire (3PH + N + G), hardwire 3-wire (1PH + N + G)
Power Output Connectors Details 6 x power IEC 60320 C13
4 x power IEC 60320 C19
1 x hardwire 3-wire (HN + G)
3 x IEC connector
Output Voltage AC 230 V ± 3% – 50/60 Hz
Power Capacity 8000 Watt / 8000 VA
Output Waveform Sinewave
Surge Suppression Yes
Surge Energy Rating 480 Joules
Efficiency 98%
Battery
Technology Lead acid
Run Time (Up To) 5.3 min at full load
14.8 min at half load
Recharge Time 3 hours
Features Maintenance free, sealed, leak-proof
Networking
Remote Management Interface Ethernet 10/100, USB
Expansion / Connectivity
Interfaces 1 x management (Ethernet) – RJ-45
1 x management (USB) – 4 pin USB Type B
1 x EPO (emergency power off)
1 x serial – RJ-45
Expansion Slots 1 (total) / 1 (free) x SmartSlot
Miscellaneous
Features Audible alarm, LCD display
Compliant Standards C-Tick, VDE, IEC 60950, EN 50091-2, RoHS, EN 50091-1, REACH, EN 62040-2, IP20, EAC
Software / System Requirements
Software Included APC PowerChute Business Edition
Manufacturer Warranty
Service & Support Limited warranty – 3 years
Limited warranty – batteries – 2 years
Environmental Parameters
Min Operating Temperature 0 °C
Max Operating Temperature 40 °C
Humidity Range Operating 0 – 95% (non-condensing)
Sound Emission 55 dBA
Dimensions & Weight
Width 43.2 cm
Depth 71.5 cm
Height 26.3 cm
Weight 111.82 kg
Dimensions & Weight (Shipping)
Shipping Width 60 cm
Shipping Depth 1 m
Shipping Height 46.1 cm
Shipping Weight 130 kg
Compatibility Information
Designed For P/N: ACCS1000, ACCS1001, ACCS1002, ACCS1003, ACCS1004, ACCS1005, ACCS1006, ACCS1007, ACDC1015, ACDC1016, ACDC1017, ACDC1019, ACDC1020, ACDC2513, AP5602, AP5606, AP5607, AP5616, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR3000, AR3100G, AR3100SP, AR3100SP1, AR3100SP2, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3101, AR3104, AR3104SP1, AR3105, AR3105SP, AR3105W, AR3107G, AR3107SP, AR3107X609, AR3107X610, AR3107X617, AR3130, AR3150SP, AR3150SP1, AR3150SP2, AR3150W, AR3150X609, AR3150X610, AR3150X617, AR3155, AR3155SP, AR3155W, AR3157SP, AR3157X609, AR3157X610, AR3157X617, AR3200, AR3300, AR3300G, AR3300SP, AR3300W, AR3300X609, AR3300X610, AR3300X617, AR3305, AR3305SP, AR3305W, AR3307, AR3307SP, AR3307W, AR3307X609, AR3307X610, AR3307X617, AR3350, AR3350SP, AR3350W, AR3350X609, AR3350X610, AR3350X617, AR3355, AR335SP, AR3355W, AR3357, AR3357SP, AR3357X609, AR3357X610

datasheet downloads APC Smart UPS SRT 8000VA Dubai
