Cisco Catalyst3750X-48L Dubai

Cisco Catalyst3750X-48L Dubai with StackWise® Plus technology provides scalability, ease of management and investment protection for the evolving business needs.

Category:

Description

Cisco Catalyst3750X-48L Network Switch Dubai

The Cisco Catalyst3750X-48L Dubai switches provide high availability, scalability, security, energy efficiency, and ease of operation with innovative features such as IEEE 802.3at Power over Ethernet Plus (PoE+) configurations, optional network modules, redundant power supplies, and Media Access Control Security (MACsec) features. The Cisco Catalyst 3750-X enhance productivity by enabling applications such as IP telephony, wireless, and video for borderless network experience.

Cisco Catalyst3750X-48L Dubai with StackWise® Plus technology provides scalability, ease of management and investment protection for the evolving business needs. The Cisco Catalyst 3750-X and 3560-X enhance productivity by enabling applications such as IP telephony, wireless, and video for borderless network experience.

Features

  • 48 10/100/1000 PoE+, non-PoE models, and 24 GE SFP port models
  • 48 10/100/1000 UPOE-capable models with Energy Efficient Ethernet (EEE) support
  • Four optional uplink network modules with GE or 10GE ports
  • Industry first PoE+ with 30W power on all ports in 1 rack unit (RU) form factor
  • Dual redundant, modular power supplies and fans
  • Media Access Control Security (MACsec) hardware-based encryption
  • Flexible NetFlow and switch-to-switch hardware encryption with the Service Module uplink
  • Open Shortest Path First (OSPF) for routed access in IP Base image
  • IPv4 and IPv6 routing, Multicast routing, advanced quality of service (QoS), and security features in hardware
  • Enhanced limited lifetime warranty (LLW) with next business day (NBD) advance hardware replacement and 90 day access to Cisco Technical Assistance Center (TAC) support
  • Enhanced Cisco EnergyWise for operational cost optimization by measuring actual power consumption of the PoE devices, reporting, and reducing energy consumption across the network
  • USB Type-A and Type-B ports for storage and console respectively and an out-of-band Ethernet management port
  • Cisco StackPower™ technology: An innovative feature and industry first for sharing power among stack members
  • Cisco StackWise Plus technology for ease of use and resiliency with 64 Gbps of throughput
  • Investment protection with backward compatibility with all other models of Cisco Catalyst 3750 Series Switches

Technical Specs

Manufacturer Cisco Systems, Inc
Manufacturer Part Number WS-C3750X-48T-L
Product Type Switch – 48 ports – Managed – stackable
Form Factor Fixed, Rack Mountable 1U, Stackable/Clustering
Switch Port density – Uplinks 48 x 10/100/1000 Ethernet Ports
Performance Switching capacity : 160 Gbps
Max Number of Stacks 9
Remote Management Protocol SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, FTP, TFTP, SSH, CLI
Authentication Method Kerberos, Secure Shell (SSH), RADIUS, TACACS+
Features Hot swap module replacement, Layer 2 switching, dynamic IP address assignment , DHCP support, auto-negotiation, ARP support, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, traffic shaping, Broadcast Storm Control, High Availability, Multicast Storm Control, Unicast Storm Control, Rapid Spanning Tree Protocol (RSTP) support, DHCP snooping, Dynamic Trunking Protocol (DTP) support, Port Aggregation Protocol (PAgP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Per-VLAN Spanning Tree Plus (PVST+)
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s
DRAM Memory 256 MB
Flash Memory 128 MB Flash
LED Status Lights Indicators Port status, link activity, port transmission speed, port duplex mode, power, system
Connectivity / Expansion Slots
Interfaces
  • 48 x 10Base-T/100Base-TX/1000Base-T – RJ-45
  • USB : 1 x 4 PIN USB Type A
  • 1 x console – mini-USB Type B – management
  • 1 x RS-232 – RJ-45 – management
  • 1 x 10Base-T/100Base-TX – RJ-45 – management
  • Network stack device : 2 x
Expansion Slot(s) 1 (total) / 1 (free) x Expansion Slot
Power Supply Specifications
Power Device Power supply – redundant – plug-in module
Installed Qty 1 (installed) / 2 (max)
Power Redundancy Optional
Power Redundancy Scheme 1+1 (with optional power supply)
Voltage Required AC 120/230 V ( 50/60 Hz )
Features Redundant Power System (RPS) connector
Dimensions / Weight / Miscellaneous
Width 44.5 cm
Depth 46 cm
Height 4.5 cm
Weight 7.4 kg
Rack Mounting Kit Optional
MTBF 171,846 hour(s)
Compliant Standards CE, TUV GS, CISPR 22 Class A, GOST, cUL, NOM, VCCI Class A ITE, EN55022 Class A, CB, AS/NZS 60950-1, AS/NZ 3548 Class A, CCC, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, KCC, FCC Part 15 A, CSA C22.2 No. 60950-1
System Software
Software Included Cisco IOS LAN Base
