Cisco Catalyst1000-24FP4XL Dubai

Rating

Cisco Catalyst1000-24FP4XL Dubai

The Cisco Catalyst1000-24FP4XL Dubai uses intelligent power management to provide flexible power allocation across all the 30W ports. With Perpetual PoE, the PoE+ power is maintained during a switch reload.

Category:

Description

Cisco Catalyst1000-24FP4XL Network Switch Dubai

Cisco Catalyst1000-24FP4XL Dubai Switches are fixed managed Gigabit Ethernet enterprise-class Layer 2 switches designed for small businesses and branch offices. These are simple, flexible and secure switches ideal for out-of-the-wiring-closet and critical Internet of Things (IoT) deployments. Cisco Catalyst 1000 operate on Cisco IOS Software and support simple device management and network management via a Command-Line Interface (CLI) as well as an on-box web UI. These switches deliver enhanced network security, network reliability, and operational efficiency for small organizations.

Expand your small business’s network capacity to support PoE network devices such as IP cameras, VoIP phones, and access points with the Cisco Catalyst1000-24FP4XL Dubai PoE+ Compliant Managed Switch from Cisco. This managed rack mountable switch features 24 PoE+ compliant Gigabit ports with a 370W budget in addition to four 10G SFP+ ports for fiber uplink connections to compatible devices. Use the intuitive web-based or command line interface to configure and manage your network with a broad selection of Layer 2 features.

Features:

Intelligent PoE

The Cisco Catalyst1000-24FP4XL Dubai uses intelligent power management to provide flexible power allocation across all the 30W ports. With Perpetual PoE, the PoE+ power is maintained during a switch reload.

Reliable Performance

Powered by an 800 MHz ARM processor with 512MB of memory, the Cisco Catalyst1000-24FP4XL Dubai helps to ensure smooth data transfers with a 56 Gb/s switching capacity and 41.67 Mbps forwarding rate.

Easy Management

Use the web-based or command line interface to configure, manage, and monitor your network.

Security

The Cisco Catalyst1000-24FP4XL features 802.1x support for connected devices in addition to a Switched Port Analyzer (SPAN), Access Control List, Bridge Protocol Data Unit (BPDU) Guard, and more.

Technical Specs

Product Code

C1000-24FP-4X-L

Description 24x 10/100/1000 Ethernet PoE+ ports and 370W PoE budget, 4x 10G SFP+ uplinks
Gigabit Ethernet ports 24
Uplink interfaces 4 SFP+
PoE+power budget 370W
Fanless N
Dimensions (WxDxH in inches) 17.5 x 13.59 x 1.73
CPU ARM v7 800 MHz
DRAM 512 MB
Flash memory 256 MB
Forwarding bandwidth 64 Gbps
Switching bandwidth 128 Gbps
Forwarding rate(64—byte L3 packets) 41.67 Mpps
