Cisco CBS350-8XT Dubai

Rating

Cisco CBS350-8XT Dubai

The Cisco CBS350-8XT Dubai is equipped with an 800 MHz ARM processor and 512MB of memory, which work to deliver smooth and reliable data transfers with a 160 Gb/s switching capacity and 119.05 Mbps forwarding rate.

Category:

Description

Cisco CBS350-8XT Network Switch Dubai

The Cisco CBS350-8XT Dubai switch is part of the fully managed switch line that delivers reliable and secure connectivity for small business networks. These switches accelerate your digital transformation by delivering full Layer 2/3 capabilities, intuitive web dashboard, advanced networking features, and PoE+ support.

This managed rackmount switch features eight 10G Ethernet ports that work with compatible wired devices such as computers, network attached storage, and more. There are also two 10G fiber SFP+ / copper RJ45 combo ports available for high-speed uplinks. Its extensive Layer 2 and Layer 3 features include secure connections, clear communications, and link aggregation to create up to eight port groups for multi-Gig connections to compatible devices. Its 160 Gb/s switching capacity and 119.05 Mbps forwarding rate also help to ensure smooth and reliable data transfers. Use the Cisco Business Dashboard portal and mobile app to configure and monitor the Cisco CBS350-8XT Dubai and its connected devices. The dual-fan design helps to maintain optimal temperatures while the switch operates quietly in the background.

Features:

Performance

The Cisco CBS350-8XT Dubai is equipped with an 800 MHz ARM processor and 512MB of memory, which work to deliver smooth and reliable data transfers with a 160 Gb/s switching capacity and 119.05 Mbps forwarding rate.

Extensive Security

  • Support for features such as IEEE 802.1x and port security limits access to specific segments of your network while web-based authentication provides a consistent interface to all types of host devices and operating systems.
  • Advanced defense mechanisms such as dynamic Address Resolution Protocol (ARP) inspection, IP Source Guard, and Dynamic Host Configuration Protocol (DHCP) snooping, help to detect and block network attacks. When combined, these protocols may be referred to as IP-MAC port binding (IPMB).
  • The IPv6 First Hop Security suite includes ND inspection, RA guard, DHCPv6 guard, and neighbor binding integrity check to protect your IPv6 network against a range of address spoofing and man-in-the-middle attacks.

IPv6 Support

The Cisco CBS350-8XT Dubai switch allows you to evolve your network using the IPv6 standard while remaining compatible with previous-generation IPv4 networks.

Layer 3 Static Routing

Dynamic Layer 3 routing features include the ability to segment your network into separate workgroups and communicate across VLANs without degrading application performance, which allows you to manage your switch’s internal routing and dedicate your router to external traffic and security to help your network run efficiently.

True Stacking

Reduce the complexity of your network while enhancing your control over a growing network by configuring, managing, and troubleshooting all your switches in a stack as a single unit using a single IP address. True stacking also provides other benefits through features such as cross-stack QoS, VLANs, LAGs, and port mirroring.

Compact Design

With a sleek and compact 1 RU design, the Cisco CBS350-8XT Dubai can fit into wiring closets and other areas within retail stores, offices, and other businesses.

Energy Efficient

Support for the Energy Efficient Ethernet (IEEE 802.3az) standard helps to significantly reduce energy consumption by monitoring the amount of traffic an active link receives and putting it to sleep during down times.

Technical Specs

Product Name CBS350-8XT-NA Managed 8-Port 10GE, 2x10G SFP+ Shared
Manufacturer Part Number CBS350-8XT-NA
Product Type Ethernet Switch
Manageable Yes
Ethernet Technology 10 Gigabit Ethernet
Number of Total Expansion Slots 2
Product Family Business 350
Stack Port Yes
Media Type Supported Optical FiberTwisted Pair
Total Number of Network Ports 8
Expansion Slot Type SFP+
Power Consumption 50.30 W
Power Source Power Supply
Layer Supported 3
Environmentally Friendly Yes
Environmental Certification WEEE
Number of SFP+ Slots 2
Modular Yes
Shared SFP Slot Yes
Port / Expansion Slot Details 6 x 10 Gigabit Ethernet Network2 x 10 Gigabit Ethernet TP/SFP+ Combo
Country of Origin China
Height 1.7″
Width 17.3″
Depth 8″
Product Series 350
Product Model CBS350-8XT
Network Technology 10GBase-T10GBase-X
Product Line Business
Input Voltage 120 V AC230 V AC
Limited Warranty Lifetime
Frequency 50 Hz60 Hz
