D-Link DPH-150SE Dubai

Rating

D-Link DPH-150SE Dubai

D-Link DPH-150SE Dubai can be installed on LAN /DSL/Cable network environment and registered to SIP registrar Server(s), soft switch(es), IP-PBX(s), or IMS-based system and let SIP-enabled terminals to communicate with.

Category:

Description

D-Link DPH-150SE IP Phone Phone

The D-Link DPH-150SE Dubai is a modern IP Phone that has been specifically designed for office users in SOHO, SMBs, and VSEs. It comes in an elegant designed that catches the eye of anyone that walks into the room. DPH-150SE Dubai is packed with a variety of advanced features that not only boost your communication experience, but also enhances your productivity.

D-Link DPH-150SE Dubai can be installed on LAN /DSL/Cable network environment and registered to SIP registrar Server(s), soft switch(es), IP-PBX(s), or IMS-based system and let SIP-enabled terminals to communicate with. Beyond this, users PC can be connected to this phone instead of LAN directly. The phone comes with a plastic Housing and some accessories, including handset, handset cord, keypad, keys and wall-mounting kit. A TFT colour LCD display on the panel provides direct visual interface with user. User can use keypad/LCD or Web browser to configure this phone.

Features

  • High-quality voice
    • D-Link DPH-150SE Dubai supports QoS, which ensures the quality of the transmission and reception of voice, similar to using a regular telephone line. In addition, this phone supports many useful features, including call transfer, caller ID, three-way conference and function of “Speed Dial”. All it convenient to dial out or answer phone calls.
  • Simultaneous search for pages in the Internet and make phone calls
    • D-Link DPH-150SE Dubai has 2 Ethernet ports, one of which is designed to connect to a cable / DSL-modem or a broadband router. The second Ethernet port lets you connect a personal computer. In this case it will be possible to simultaneously talk on IP-phone and search pages on the Internet, send emails, transfer files and perform other network tasks on the computer.

D-Link DPH-150SE – Technical Specifications

Network interface
• WAN Port 10/100Base-TX Ethernet with PoE support
• LAN Port 10/100Base-TX Ethernet
• 5V DC IN Jack
• Handset Hook switch
• Handset Jack
• External console Jack
Keypad Features
• 4 Soft keys for doing more functions
• 8 DSS keys
• 4 Navigator Keys and 1 ok key for navigating in configuration
• Hold
• Call forward
• Three-party conference
• MWI
• Headset
• Redial (Redial and the entry to access call history; finish dialling and call the number)
• Speaker
• 12 numeric keys with star & pound key
• Mute
• Vol – / Vol +
Hardware
• CPU: BCM 1190
• SDRAM: 16 M
• FLASH: 8 M
LCD
• 2.8 inch Colour LCD
• Resolution: 320×240,TFT colour LCD
Physical
• Dimension: 195 A— 188 A— 51 mm
• Net Weight: 0.51kg
Power Adaptor
• AC-DC Switching Power switching
• Wall-Mount type
• Input: 100~120, 220~240VAC
• Output: DC 5V / 0.6A
• Max. Watt: 5 Watt.
• IEEE802.3af  POE Class 1
Power Consumption
• Typical: 1.3 Watt (Standby)
• Max.: 4.3 Watt (Talking)
