D-Link DPH400G Dubai

The D-Link DPH400G Dubai combines the industry’s modern Voice over IP network (VoIP) technology with progressive communication features and is friendly with industry-wide phone services.

Category:

Description

D-Link DPH400G IP Phone Dubai

The D-Link DPH400G Dubai offers versatile features and specifications to meet different environmental .reԛuirements.It can be installed on LAN /DSL/Cable network environment and registered to SIP registrar Server(s), soft switch (es), IP-PBX(s), or IMS-based system and let SIP-enabled terminals to communicate with. Beyond this, user’s PC can be connected to this phone instead of LAN directly. The phone comes with a plastic Housing and some accessories, including handset, handset cord, keypad, keys, and wall-mounting kit. A 3.5 Inch LCD Colour display on the panel provides a direct visual interface with the user. The user can use keypad/LCD or Web browser to configure this phone.

The D-Link DPH400G Dubai SIP Business Phone is an internet phone good for home and office telephone system. The DPH-400GE IP Phone allows you to take benefits of your internal Network to make office communication calls. It combines the business new Voice over IP network technology with modern communication features and is matched with business extensive range phone features.

The D-Link DPH400G Dubai combines the industry’s modern Voice over IP network (VoIP) technology with progressive communication features and is friendly with industry-wide phone services. D-Link combines the ԛualities of an old desktop phone with all the benefits of VoIP technology to create a modern designed phone perfect for the home or office. The D-Link DPH-400GE F4 SIP Business Phone combines Quality of Service to confirm that the voice received over the network is the same and natural as surpasses – that received on a normal phone.

Dl-Link DPH400G Dubai Office IP Phone has some rich functions such as VAD, Packet Loss Concealment, Silence Defeat, and other features expand the ԛuality of voice communication, providing excellence in sound and performance. The DPH- 400GE IP Phone can store up to 500 contact names and phone numbers in phonebook which is already built in.  Long call log of 300 allows you to keep track of missed, received and dialled calls and caller ID lets you see all incoming calls data.

Features

  • 3.5 inch Color LCD with Resolution: 480 x 320
  • 6 VoIP/ SIP Accounts
  • Caller ID display (Incoming call & CWI)
  • Call log: 300 Calls
  • Phonebook (up to 300 contact names and phone numbers)
  • Supports XML Phonebook/Browser
  • Supports click to dial via web phonebook
  • Day/Time display
  • Call timer display
  • 4 Soft keys for doing more functions
  • 10 DSS keys
  • Incoming call indicator
  • User/Admin Password control for Configuration
  • Silence Suppression
  • Acoustic Echo Cancellation (G.167)
  • Voice Activation Detection (VAD)
  • Comfort Noise Generation
  • Dynamic Jitter Buffer
  • DTMF Transmitter (SIP info, Transparent, RTC 2833 relay)
  • Packet Loss Concealment (PLC)
  • QoS: IEEE 802.1Q & IEEE 802.1p Compliant
  • L2TP VPN/OpenVPN
  • Class of Service Support by VLAN Tag /Full range VLAN ID Support

D-Link DPH400G – Technical Specifications

Network Interface and I/O Ports

WAN Port: to connect to 10/100/1000Mbps Ethernet

LAN Port: to connect to 10/100/1000Mbps Ethernet

5V DC IN Jack: for switching power adaptor

Handset Hook switch: for hang on/off control on handset cradle

Handset Jack: to connect with a handset

Headset Jack: to connect with a headset

External console Jack: to connect with expansion module

General

Keypad Features

4 Soft keys for doing more functions

10 DSS keys

4 Navigator Keys for navigating in configuration

Hold

Call forward

Three-party conference

Phone Book

MWI

Headset

Redial

12 numeric keys with star & pound key

Mute

Vol-/Vol+

 Phone Features

Multi-user (6 SIP accounts)

Caller ID display

Call History: 300 Calls

Phone book (up to 500 contact)

Remote phonebook (up to 4 xml phonebook)

Day/Time display

Call/Time display

9 Selective Ring tones

9 Speed dial number

Incoming call indicator

Flexible dial map

Password control for Configuration + Pre-dial before sending

Connect with expansion module

MWI

SMS

Keypad lock

Emergency call

Customize DSS key/ softkey

Voice Codec

G.711a/u (64k bps)

G.729A/B (8k bps)

G.723.1 high/low

G.726-32

G.722

 Advance Voice Quality Feature

Silence Suppression

Acoustic Echo Cancellation (G.167)

Voice Active Detection (VAD)

Comfort Noise Generation

Jitter Buffer

DTMF Transmitter (SIP info, Transparent, RFC 2833)

Packet Lost Concealment

 Signal, Media & Network Protocols

SIP RFC 3261 & the related RFC standard in Appendix A

SDP RFC 2327, RTP RFC 1889

IP assignment: Static IP, DHCP and PPPoE

STUN, static port mapping (for NAT traversal)

SNTP, DNS & DNS SRV

TFTP/FTP/HTTP/HTTPS for Auto Provision

IP/TCP/UDP/ARP/ICMP

Route and Bridge mode

 Supplementary Call Feature

Call Hold Resume, Mute, Waiting, Call waiting Indication

Three Way Conference, Anonymous Call/Rejection

Message Waiting Indication, Auto Answer, Black list, Limit list

Auto hang-up, Auto Redial, Ban outgoing, Hotline, BLF/Presence

Action url/Active uri

Network Capability

QoS: IEEE 802.1Q & IEEE 802.1p Compliant

Diffserv (DSCP)/ToS, Full range VLAN ID Support

Class of Service Support by VLAN Tag, LLDP, L2TP VPN/ OpenVpn

USER INTERFACE AND NETWORK MANAGEMENT

LCD/Keypad UI in English & other Languages

HTTP(WEB) UI in English version & other Languages

FTP/TFTP/HTTP for Firmware remote update

Auto-provisioning (APS) for firmware and profile upgrade
