Grandstream GWN7615 Wireless Access Point Dubai

Grandstream GWN7615 Dubai is a business-grade performance 802.11ac Wave-2 Wi-Fi Access Point in Dubai which is specifically designed to deliver maximum scalability for medium to high user density environments. Its sophisticated antenna design enables it to deliver maximum network throughput as well as an expanded Wi-Fi coverage range. The Grandstream GWN7615 Wi-Fi Access Point Dubai provides you with a robust dual-band 3×3:3 MU-MIMO technology. For easy installation and management, the Grandstream GWN7615 Dubai uses a controller-less distributed network management design in which the controller is embedded within the product’s web user interface.

Description

Grandstream GWN7615 Wireless Access Point Dubai

The Grandstream GWN7615 WirelessAccess Point Dubai supports GWN Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platforms. Grandstream GWN7615 Dubai is the ideal Wi-Fi AP for voice-over Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi-capable IP phones. With support for advanced QoS, low-latency real-time applications, mesh networks, captive portals, 200+ concurrent clients per AP and dual Gigabit network ports with PoE/PoE+, the Grandstream GWN7615 Dubai can be used to create a scalable solution as big or small as needed for the deployment scenario, from office buildings to retail locations, hotels and more.

Grandstream GWN7615 Access Point Features

Dual-band MU-MIMO:

The dual-band 3×3:3 technology with beam-forming solutions from Grandstream offers a sophisticated way to upgrade your network throughput and improve your Wi-Fi coverage range – no matter what kind of business environment you run.

Integrated Dual-band Wi-Fi Radio

The Grandstream GWN7615 Wireless Access Point Dubai comes with a built-in dual-band Wi-Fi 802.11 a/b/g/n/ac which provides a fast network signal for smooth conference calls over the internet at speeds of 2.4GHz and 5GHz.

Wide Coverage Range

The Grandstream GWN7615 Wireless Access Point Dubai is a highly efficient and reliable device that offers a long coverage range of up to 175 meters which can vary depending on the kind of environment used.

Easy installation and management:

The Grandstream GWN7615 Wireless Access Point Dubai simplifies the management of your connectivity network with a controller-less network management design. An embedded controller in a web user interface allows you to manage a system of up to 50 Apps without needing a separate piece of controller software or hardware. There’s also no single point of failure to worry about

Flexibility:

This unique wireless access point from Grandstream pairs seamlessly with routers from third-party companies, as well as the leading routers from the Grandstream GWN series, so that you can build the connectivity environment that’s best suited to your needs, without vendor lock-in.

Advanced performance

The Grandstream GWN7615 Wireless Access Point Dubai comes with support for real-time applications and low latency, as well as advanced QoS and more than 200 devices per AP. There are even extra features like dual Gigabit ports with access to PoE.

Cloud Management

Grandstream provides a reliable and secure cloud service to deliver connectivity to its users at cheaper maintenance costs while enhancing operation and maintenance efficiency. The cloud service on the internet enables customers to gain direct access to Grandstream devices available in private networks such as IP-PBXs, audio gateways, and IP phones, therefore allowing simple remote maintenance and management of Grandstream devices. This kind of cloud service is specifically designed to meet the needs of large-scale installation, configuration, and maintenance and operation. Auto-provisioning and configuration backup, online update, real-time monitoring and alert enable users to achieve efficient operation and maintenance, thus maximizing productivity in organizations.

Supports Power over Ethernet

The Grandstream GWN7615 Wireless Access Point Dubai is equipped with Dual 10/100Mbps ports which are integrated with Power over Ethernet to allow for convenient installation and a variety of remote features including provisioning, status monitoring and handset firmware upgrades.

Interoperability

Grandstream GWN7615 wireless access point Dubai can be paired with any third-party router as well as Grandstream’s GWN series routers. Supporting advanced QoS, low-latency real-time applications, 200+ client devices per AP as well as dual Gigabit network ports with PoE/PoE+.

Grandstream GWN7615 Key Features

  • 75Gbps aggregate wireless throughput and 2x Gigabit wireline ports
  • Dual-band 3×3:3 MU-MIMO technology
  • Self-power adaptation upon auto detection of PoE or PoE+
  • Support 200+ concurrent Wi-Fi client devices
  • Up to 175-meter coverage range
  • Advanced QoS to ensure real-time performance of low-latency applications
  • Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
  • Embedded controller can manage up to 50 local GWN series APs; GWN.Cloud offers unlimited AP management; GWN Manager offers premise-based software controller

Grandstream GWN7615 Access Point Specifications

Wi-Fi Standards

  • IEEE 802.11 a/b/g/n/ac (Wave-2)

Antennas

  • 3 dual band internal antennas
  • 4GHz, gain 3dBi
  • 5 GHz, gain 3dBi

Wi-Fi Data Rates

  • IEEE 802.11ac: 6.5 Mbps to 1300Mbps
  • IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
  • IEEE 802.11n: 6.5 Mbps to 450 Mbps
  • IEEE 802.11b: 1, 2, 5.5, 11Mbps
  • IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
  • *Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network

Frequency Bands

  • 4 GHz Radio: 2412 – 2484 MHz
  • 5 GHz Radio: 5180-5825 MHz

Channel Bandwidth

  • 4G: 20 and 40MHz
  • 5G: 20, 40, and 80MHz

Wi-Fi and System Security

  • WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device

MIMO

  • 3×3:3 2.4G(MIMO)
  • 3×3:3 5G(MU-MIMO)

Coverage Range

  • Up to 175 meters
  • *coverage range can vary based on the environment

Maximum TX Power

  • 4G: 26 dBm
  • 5G: 24 dBm
  • *Maximum power varies by country, frequency band and MCS rate

Receiver Sensitivity

  • 4G: 802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps; 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7
  • 5G: 802.11a: -92dBm @6Mbps, -74dBm @54Mbps; 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: HT40:- 63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9

SSIDs

  • 16 SSIDs per access point

Concurrent clients

  • 200+

Network Interfaces

  • 2x autosensing 10/100/1000 Base-T Ethernet Ports

Auxiliary Ports

  • 1x Reset Pinhole, 1x Kensington lock

Mounting

  • Indoor wall or ceiling mount, kits included

LEDs

  • 3 x tri-color LEDs for device tracking and status indication

Network Protocols

  • IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM

QoS

  • 11e/WMM, VLAN, TOS

Network Management

  • Embedded controller can manage up to 50 local GWN APs
  • Cloud offers a free cloud management platform for unlimited GWN APs
  • GWN Manager offers premise-based software controller for up to 3,000 GWN APs

Power and Green Energy Efficiency

  • PoE 802.3af/ 802.3at;
  • Max Consumption: 12.5W

Environmental

  • Operation: 0°C to 40°C
  • Storage: -10°C to 60°C
  • Humidity: 10% to 90% Non-condensing

Physical

  • Unit Dimension: 205.4 x 205.4 x 45.9mm;
  • Unit Weight: 500g
  • Entire Package Dimension: 258 x 247 x 86mm;
  • Entire Package Weight: 867.3g

Package Content

  • GWN7615 802.11ac Wireless AP, Mounting Kits, Quick Start Guide

datasheet downloads Grandstream GWN7615 Wireless Access Point Dubai
