Ubiquiti USW-48PoE Dubai

Rating

Ubiquiti USW-48PoE Dubai

The versatile Ubiquiti USW-48PoE Dubai provides Gigabit PoE links to Ethernet devices while also supplying Gigabit fiber uplink options fit for an enterprise network. The ubiquiti Switch-48PoE Dubai also offers an extensive suite of Layer 2 switching protocols.

Description

Ubiquiti USW-48PoE Network Switch Dubai

The Ubiquiti USW-48PoE Dubai is a fully managed switch with (48) GbE RJ45 ports, including (32) GbE, 802.3at PoE+ ports, and (4) 1G SFP ports. The versatile USW 48 PoE provides Gigabit PoE links to Ethernet devices while also supplying Gigabit fiber uplink options fit for an enterprise network. The Ubiquiti USW-48PoE Dubai also offers an extensive suite of Layer 2 switching protocols, including port-specific operation modes (switching, mirroring, or aggregate), and features a 1.3″ LCM color touchscreen that concisely displays key system and connection insights. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

The Ubiquiti USW-48PoE Dubai features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server. The Ubiquiti USW-48PoE Dubai is the ideal access layer switch for any UniFi solution – it combines up to 600W of near-silent PoE power with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere.

Features:

  • (1) 1.3″ LCM color touchscreen with AR switch management
  • (32) GbE, 802.3at PoE+ RJ45 ports
  • (16) GbE RJ45 ports
  • (4) 1G SFP ports
  • 195W total PoE supply
  • Fanless, silent cooling

Technical Details

Mechanical
Dimensions 442.4 x 285 x 43.7 mm
(17.42 x 11.22 x 1.72″)
Weight
With Rackmount Brackets
4.52 kg (9.97 lb)
4.61 kg (10.16 lb)
Interfaces
Networking Management
(48) 10/100/1000 RJ45 Ports
(4) 1G SFP Ethernet Ports
Ethernet In-Band
Total Non-Blocking Throughput 52 Gbps
Switching Capacity 104 Gbps
Forwarding Rate 77.38 Mpps
Power Method 100-240VAC, 50/60 Hz, Universal Input
Power Supply AC/DC, Internal, 240W
Supported Voltage Range 100 to 240VAC
Max. Power Consumption (Excluding PoE Output) 45W
LEDs
RJ45 Data Ports
SFP Data Ports
PoE; Speed/Link/Activity
Link/Activity
ESD/EMP Protection Air: ± 16 kV, Contact: ± 12 kV
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 10 to 90% Noncondensing
Certifications CE, FCC, IC
PoE
Total Available PoE 195W
PoE Interfaces
Ports 1-32
POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
Max. PoE Wattage per Port by PSE
802.3at
32W
Voltage Range 802.3af Mode 44-57V
Voltage Range 802.3at Mode 50-57V
