Ubiquiti USW-FlexMini Dubai

Rating

Ubiquiti USW-FlexMini Dubai

With its small, fanless desktop design, the Ubiquiti USW-FlexMini Dubai fits into almost any office, home, or business environment, where it operates silently.

Description

Ubiquiti USW-FlexMini Network Switch Dubai

The Ubiquiti USW-FlexMini Dubai is a fully managed, Layer 2 switch with (5) GbE RJ45 ports, including (1) 802.3af PoE input. The USW Flex Mini can be powered with either PoE (via Port 1) or its included USB-C power adapter. This switch can also be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Expand your network with the compact Ubiquiti USW-FlexMini Dubai 5-Port Gigabit Managed Switch from Ubiquiti Networks. This 5-port fully managed router features five RJ45 Gigabit Ethernet ports that provide fast, wired connections to compatible devices, supporting a 10 Gb/s switching capacity and 7.44 Mbps forwarding rate. The Ubiquiti USW-FlexMini Dubai can also be powered through its PoE-in port when connected to a compatible 802.3af/at device or using the included USB Type-C power adapter. With its small, fanless desktop design, the Ubiquiti USW-FlexMini Dubai fits into almost any office, home, or business environment, where it operates silently. Use the UniFi Network Controller platform (version 5.12.5 or higher) to configure, manage, and monitor the switch and its connected devices.

Features:

  • (1) GbE, 802.3af PoE RJ45 input
  • (4) GbE RJ45 ports
  • Compact, slim housing
  • Can be powered with a 5V, 1A USB-C adapter

Technical Specs

Mechanical
Dimensions 107.16 x 70.15 x 21.17 mm (4.22 x 2.76 x 0.83″)
Weight 150 g (5.29 oz)
Interfaces
Networking
PoE In
Management
(5) 10/100/1000 Mbps RJ45 Ports
802.3af/at PoE (Pins 1, 2+; 3, 6-)
Ethernet In-Band
Total Non-Blocking Throughput 5 Gbps
Switching Capacity 10 Gbps
Forwarding Rate 7.44 Mpps
Power Method USB Type C, 5V
802.3af/at PoE (44 – 57VDC, 0.05 – 0.04A)
Power Supply 5V, 1A Power Adapter*
Voltage Range
USB Type C
802.3af/at PoE
4.7 – 5.3VDC
44 – 57VDC
Max. Power Consumption 2.5W
LEDs
System
RJ45 Data Ports
Status
Speed/Link/Activity
ESD/EMP Protection ± 16kV Air, ± 12kV Contact
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature -5 to 45° C (23 to 113° F)
Operating Humidity 10 to 90% Noncondensing
Certifications CE, FCC, IC
