Ubiquiti USW-Pro24PoE Dubai

Rating

Ubiquiti USW-Pro24PoE Dubai

The Ubiquiti USW-Pro24PoE Dubai features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server.

Description

Ubiquiti USW-Pro24PoE Network Switch Dubai

The Ubiquiti USW-Pro24PoE Dubai is a fully managed switch with (16) GbE, 802.3at PoE+ RJ45 ports, (8) GbE, 802.3bt PoE++ RJ45 ports, and (2) 10G SFP+ ports. The USW Pro 24 PoE combines a rich set of Layer 2 features with advanced Layer 3 tools including inter-VLAN routing, static routing, and a DHCP server. The Ubiquiti USW-Pro24PoE Dubai is the ideal access layer switch for any UniFi system. It combines up to 400W of PoE power with SmartPower RPS (USP RPS) power redundancy. The Ubiquiti USW-Pro24PoE Dubai can also be monitored and configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Ubiquiti USW-Pro24PoE Dubai is a fully managed Layer 3 switch with (8) 802.3bt (PoE++) and (16) 802.3at (PoE+) Gigabit Ethernet ports. (2) 10G SFP+ uplinks offer link aggregation for higher capacity and increased availability. The Ubiquiti USW-Pro24PoE Dubai features a rich set of Layer 2 capabilities and integrates Layer 3 functionality such as inter-VLAN routing, static routing, and DHCP server. The Ubiquiti USW-Pro24PoE is the ideal access layer switch for any UniFi solution – it combines up to 400W of near-silent PoE power with UniFi SmartPower RPS power redundancy. UniFi Network Controller and UniFi Network mobile app allow admins to configure and monitor virtually all of the switch features in an intuitive graphical user interface from anywhere.

Features:

  • (1) 1.3″ LCM color touchscreen with AR switch management
  • (16) GbE, 802.3at PoE+ RJ45 ports
  • (8) GbE, 802.3bt PoE++ RJ45 ports
  • (2) 10G SFP+ ports
  • (1) USP RPS DC input
  • 400W total PoE supply
  • Near-silent cooling
  • Layer 3 switching features

Technical Specs

Mechanical
Dimensions 442.4 x 285.4 x 43.7 mm
(17.42 x 11.24 x 1.72″)
Weight
With Rackmount Brackets
4.30 kg (9.48 lb)
4.39 kg (9.68 lb)
Interfaces
Networking Management
(24) 10/100/1000 RJ45 Ports
(2) 1/10G SFP+ Ethernet PortsEthernet In-Band
Total Non-Blocking Throughput 44 Gbps
Switching Capacity 88 Gbps
Forwarding Rate 65.472 Mpps
Power Method
Universal Input
USP RPS DC Input
100-240VAC/50-60 Hz
52VDC, 7.69A; 11.5VDC, 2.61A
Power Supply AC/DC, Internal, 450W
Supported Voltage Range 100 to 240VAC
Max. Power Consumption (Excluding PoE Output) 50W
LEDs
System
RJ45 Data Ports
SFP+ Data Ports
Status
PoE; Speed/Link/Activity
Link/Activity
ESD/EMP Protection Air : ± 16 kV, Contact : ± 12 kV
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature -5 to 40° C (23 to 104° F)
Operating Humidity 10 to 90% Noncondensing
Certifications CE, FCC, IC
